Description
ADJUST TO YOUR NEEDS
We transferred some adjustments from the vision chassis to the pro chassis, improved them, and added a lot of new adjustability features. The adjustable buttstock has been improved both in stiffness and feel. The forend is even longer with more M-loks and our new V-Løk attachment system, and has the possibility to add 1kgs/2lbs of internal weights. And last but not least, the magazine well features height and length adjustment to get the perfect magazine fit.
ZERO VIBRATIONS
Have you ever been dryfiring and heard the vibrations in your chassis when pulling the trigger? well, due to design and material choices you won’t with the Vision Pro Chassis. A common fix to this issue is to add rubber parts to your chassis, but with the Vision Pro Chassis you won’t have to even consider it.
OPTIMIZED BALANCE POINT
With the Vision PRO Chassis we listened to feedback and moved the barricade stop as close to the magazine as we could. As a result of this and design choices we managed to achieve an insanely good balance point. With a full profile 26″ barrel and zero weights the balance point sits three inches in front of the barricade stop, which can then be moved further with the use of weights.
SPECIFICATIONS:
WEIGHT:
2.52 kg / 5lbs 12oz
MATERIALS:
Aircraft-Grade 7075 Aluminum
FINISH:
Elite Series Cerakote With Hard Anodized Parts.
FOREND LENGTH:
480mm / 18.9in
TOTAL LENGTH:
960mm / 37.8in
MAGAZINE COMPATIBILITY:
AICS, AW & AX Magazine Compatible.
GRIP COMPATIBILITY:
Compatible With AR-15 Style Grips.
MAX BARREL DIAMETER:
With Top Cover : 1.250” / 31.75mm
Without Top Cover: 1.350” / 34.3mm
LENGTH OF PULL:
| Compatibility | Adapter block | LOP Adjustment 1 | LOP Adjustment 2 | LOP Adjustment 3 |
| Rem 700 SA | Short Adapter Block (7mm) | 311mm / 12.24in | 323mm / 12.72in | 335mm / 13.19in |
| Rem 700 SA | Medium Adapter block (23mm) | 327mm / 12.87in | 339mm / 13.35in | 351mm / 13.82in |
| Rem 700 SA
Tikka T3 SA Rem 700 LA |
Folding hinge adapter /
Long Adapter Block (30mm) |
334mm / 13.15in | 346mm / 13.62in | 358mm / 14.09in |
| Rem 700 SA
Tikka T3 SA Rem 700 LA |
Extra Long adapter block (35mm) | 339mm /
13.22in |
351mm /
13.70in |
363mm /
14.17in |
FEATURES:
ADJUSTABLE THUMB REST ON BOTH SIDES
FULL LENGTH ARCA FOREND
WIDE & AGGRESSIVE BARRICADE STOP
V-LØK ACCESSORIES MOUNT
AMBIDEXTROUS & TRUE VERTICALLY ADJUSTABLE MAGAZINE LATCH
QD SLING CUPS ON FOREND AND BUTTSTOCK
DRILLED AND TAPPED HOLES FOR MOUNTING TOP COVER AND NV BRIDGE
MAGAZINE LENGTH ADJUSTMENT
RRS-LOCK INTERFACE ALONG BOTTOM SURFACE OF FOREND
AMBIDEXTROUS LH/RH ORIENTATION
FOLDING HINGE COMPATIBLE
QUICK-ADJUST BUTTPAD WITH NOTICABLE CLICKS
BRIDGES INSIDE FOREND FOR SUPERIOR STRENGTH
HOLE IN TRIGGER GUARD FOR EASY TRIGGER ADJUSTMENT ACCESS
AR-15 VERTICAL GRIP
ACCESSORY MOUNT
ADJUSTABLE CHEEK REST
MACHINED CLEARANCE IN BUTTSTOCK FOR EASY BARREL CLEANING
BRACKET RAILS AND ANGLES FOR SUPERIOR STIFFNESS AND FEEL
11X M-LOKS ON BOTH SIDES OF FOREND
INTERNAL AND EXTERNAL BUTTSTOCK WEIGHTS COMPATIBLE
ATTENTION TO DETAILS:
The Vision Pro Chassis is delivered with anti-vibration washers. With these you don’t have to worry about your action screws losing torque easily.
Have you ever owned a product that had rusty screws after using it one time? This won’t happen with the Vision Pro Chassis due to our dedication to every little detail. In addition to this, all visible screws are black, simply because we think it looks much better than shiny screws.
CONTENTS OF PACKAGE:
The vision pro chassis comes pre-built which makes it plug-and-play for the end customer. In addition to this, all necessary tools for installation and adjustment are included.
Here is an overview of all included components:
VISION PRO CHASSIS BASE
VISION PRO BUTTSTOCK
VISION VERTICAL GRIP
ADJUSTABLE THUMB REST X2
